Epoxy Adhesive, DP2216 Series, Gray, Dual-Cartridge, 12 PK, 2:03 Mix Ratio, 30 min Functional Cure
| Item | Epoxy Adhesive |
|---|---|
| Type | Epoxy Adhesive |
| Application | Potting |
| Color | Gray |
| For Use On | 3M EPX Applicator |
| Container Type | Dual-Cartridge |
| Functional Cure | 30 min |
| Full Cure | 7 day |
| Mixing Ratio | 2:03 |
| Shear Strength | 3,200 psi |
| Working Time | 90 min |
| Series | DP2216 |
| Epoxy Color | Gray |
| Shear Strength (PSI) | 3,200 |
| Size | 41.5 mL |
| Coverage | 320 sq ft/gal |
| Application Method | No Special Application |
| Includes | Resin and Hardener |
| Resin Type | Epoxy |
| Structural Adhesive Type | Epoxy Adhesive |
| For Use With | 3M EPX Applicator |
| Work Life | 90 min |
| Materials Bonded | Glass, Masonry, Metal, Plastic, Rubber, Wood |
| Cured Color | Gray |
| VOC Content Weight | 3.7 g/L |
| Non-Sagging | No |
| Resin Color | White |
| Primary Applications | Potting |
| Water Resistance | Not Water-Resistant |
| Maximum Application Temperature | 80 deg F |
| Cure Method | Ambient |
| Maximum Performance Temperature | 180 deg F |
| Compatible Mixer Tip | 3M EPX |
| Compatible Applicator (Grainger Part Number) | 54XK02 |
| Compatible Applicator | 3M EPX |
| Standards | UL 94 HB |
| Compatible Primer | EC-3901 for Glass |
| Peel Strength | 25 lb/in |
| Minimum Viscosity | 40,000 cps |
| Marine Grade | No |
| Low Odor | No |
| Full Cure Time | 7 days |
| Hardener Color | Gray |
| Hardness at Full Cure | 50 to 65 Shore D |
| VOC Content Weight Percentage | Less Than 0.5% |
| Included Components | Hardener, Resin |
| Features | Environmental Resistant, Maintains A Strong Bond Under Expansion, Flexible Bond |
| Interior/Exterior | Interior Only |
| Total Volume | 41.5 mL |
| Alternate Product Name | 3M Scotch-Weld Epoxy Adhesive DP2216 |
| Maximum Viscosity | 150,000 cps |
| Container Type - Adhesives | Dual-Cartridge |
| Country of Origin (subject to change) | United States |
| Package Quantity | 12 |
