Hot Melt Adhesive, DP100FR Series, Clear, Dual-Cartridge, 1:01 Mix Ratio, 15 min Functional Cure
| Item | Hot Melt Adhesive |
|---|---|
| Type | Low Viscosity, Fast Cure |
| Application | For The Structural Bonding |
| Color | Clear |
| For Use On | 3M(TM) Dispensing Equipment |
| Container Type | Dual-Cartridge |
| Functional Cure | 15 min |
| Full Cure | 48 hr |
| Mixing Ratio | 1:01 |
| Shear Strength | 2,200 psi |
| Temp. Range | 0 to 72 deg F |
| Working Time | 6 min |
| Series | DP100FR |
| Epoxy Color | Off-White |
| Temp. Range (F) | 0 to 72 |
| Work Life | 6 min |
| Includes | Resin and Hardener |
| Size | 1.64 fl oz |
| Shear Strength (PSI) | 1,500 |
| For Use With | 3M(TM) Dispensing Equipment |
| Coverage | 320 sq ft/gal |
| Epoxy Container | Dual-Cartridge |
| Green Environmental Attribute | Does Not Contain Methylene Chloride |
| Structural Adhesive Type | Epoxy Adhesive |
| Resin Type | Epoxy |
| Application Method | No Special Application |
| Features | Antimony-Based Flame Retardant, Easy to Mix, Fast-Curing |
| Low Odor | No |
| Minimum Application Temperature | 0 deg F |
| Hardness at Full Cure | 87 Shore D |
| Maximum Performance Temperature | 180 deg F |
| Included Components | Hardener, Resin |
| Compatible Primer | EC-3901 for Glass |
| Standards | 14 CFR 25.853, UL 94 V-O |
| Maximum Viscosity | 120,000 cps |
| Water Resistance | Not Water-Resistant |
| Materials Bonded | Ceramic, Glass |
| Cured Color | Cream |
| Marine Grade | No |
| Tensile Strength | 2,200 psi |
| Primary Applications | Flame Retardant |
| VOC Content Weight | 0 g/L |
| Peel Strength | 2 lb/in |
| Compatible Applicator | 3M EPX |
| Total Volume | 48.5 mL |
| Interior/Exterior | Exterior, Interior |
| Non-Sagging | Yes |
| Cure Method | Ambient |
| Compatible Applicator (Grainger Part Number) | 54XK02 |
| Maximum Application Temperature | 80 deg F |
| Compatible Mixer Tip | 3M EPX |
| Full Cure Time | 48 hr |
| Minimum Viscosity | 40,000 cps |
| VOC Content Weight Percentage | 0% |
| Weight | 13 oz |
| Container Type - Adhesives | Dual-Cartridge |
| Country of Origin (subject to change) | United States |
| Package Quantity | 1 |
