Hot Melt Adhesive, DP110 Series, Amber, Dual-Cartridge, 12 PK, 1:01 Mix Ratio
| Item | Hot Melt Adhesive |
|---|---|
| Type | Duo-Pak |
| Application | May be applied with spatula, trowel, or flow equipment. |
| Color | Amber |
| For Use On | Applicator, Mixing Tip |
| Container Type | Dual-Cartridge |
| Functional Cure | 20 min |
| Full Cure | 48 hr |
| Mixing Ratio | 1:01 |
| Shear Strength | 3,500 psi |
| Temp. Range | -65 to 350 deg F |
| Working Time | 10 min |
| Series | DP110 |
| Size | 6.76 fl oz |
| Temp. Range (F) | -65 to 350 |
| Epoxy Max. Temp | 300 Degrees F and Above |
| Structural Adhesive Type | Epoxy Adhesive |
| Epoxy Color | Gray |
| Epoxy Container | Dual-Cartridge |
| Work Life | 9 min |
| Shear Strength (PSI) | 3,500 |
| For Use With | Applicator, Mixing Tip |
| Includes | Resin and Hardener |
| Coverage | 320 sq ft/gal |
| Green Environmental Attribute | Does Not Contain Methylene Chloride |
| Application Method | No Special Application |
| Resin Type | Epoxy |
| Standards | OSHA 29 CFR 1910.1200, TSCA |
| Features | Handling Strength In 20 min, Controlled Flow, Duo-Pak Cartridge Dispensing System |
| Compatible Applicator (Grainger Part Number) | 794HJ1 |
| Compatible Applicator | 3M EPX |
| Minimum Performance Temperature | -65 deg F |
| VOC Content Weight | 0 g/L |
| Non-Sagging | No |
| Maximum Viscosity | 90,000 cps |
| Hardness at Full Cure | 45 Shore D |
| VOC Content Weight Percentage | 0% |
| Included Components | Hardener, Resin |
| Primary Applications | Vibration and Impact Resistance |
| Total Volume | 200 mL |
| Hardener Color | Black |
| Maximum Application Temperature | 80 deg F |
| Tensile Strength | 3,500 psi |
| Materials Bonded | Ceramic, Glass, Metal, Plastic, Rubber, Wood |
| Interior/Exterior | Exterior, Interior |
| Peel Strength | 20 lb/in |
| Minimum Viscosity | 40,000 cps |
| Resin Color | White |
| Water Resistance | Not Water-Resistant |
| Full Cure Time | 48 hr |
| Marine Grade | No |
| Cured Color | Gray |
| Maximum Performance Temperature | 180 deg F |
| Cure Method | Ambient |
| Compatible Mixer Tip | 3M EPX |
| Low Odor | No |
| Container Type - Adhesives | Dual-Cartridge |
| Country of Origin (subject to change) | United States |
| Package Quantity | 12 |
