Shrink Tubing, 0.375in ID, Black, 6in, PK10
| Item | Heat Shrink Tubing |
|---|---|
| Shrink Ratio | 3:1 |
| Shrink Tubing Wall Type | Thin Wall |
| Shrink Tubing I.D. Before Shrinking | 3/8 in |
| Material | Polyolefin with Adhesive |
| Color | Black |
| Length | 6 in |
| Temp. Range | -67 to 230 deg F |
| Min. Shrink Temp. | 250 deg F |
| Standards | CSA File LR38227, UL E157227 |
| Shrink Tubing Adhesive Lined | Yes |
| Max. Voltage | 600 V |
| Flame Retardant | Yes |
| Shrink Tube Material Type | Flexible |
| Shrink Tubing Type | Heat Shrink Tubing |
| I.D. After Shrinking | 0.12 in |
| Use Shrink Tubing With Wire Size | 12 to 8 AWG |
| Shrink Tubing Usable Temp. Range | -67 to 230 deg F |
| Shrink Tubing Wall Thickness After Shrinking | 0.025 in |
| Shrink Tubing Material | Polyolefin |
| Features | Dual-Wall Construction, Moisture Seal Protection, Skintight Fit, Strain Relief Protection, Thermoplastic Adhesive Internal Layer |
| Shrink Tubing Length | 6 in |
| I.D. Before Shrinking | 0.38 in |
| Use With Wire Size | 12 AWG to 8 AWG |
| Tubing Wall Type | Thin Wall |
| Adhesive Lined | Yes |
| Shrink Tubing Properties | Abrasion Resistant, Acid and Alkali Resistant |
| Max. Temp. Rating | 230 deg F |
| Package Style | Individual Pieces |
| Wall Thickness After Shrinking | 0.03 in |
| Dielectric Strength | 600 V |
| Min. Temp. Rating | -67 deg F |
| Length (Straight Wireway) | 6 in |
| Tensile Strength | 2100 Pound-Force Per Square Inch |
| Family | 3Mâ„¢ Heat Shrink EPS-300 |
| Operating Temperature (Fahrenheit) | -67 to 230°F |
| Non-Corrosive | Yes |
| Solution for | Wireless Network: Infrastructure Accessories |
| Recovered Inner Diameter (metric) | 3.1 mm |
| Expanded Inner Diameter (metric) | 9.5 mm |
| Operating Temperature Range (Celsius) | -55 to 110°C |
| Recovered Inner Diameter | 0.12 in |
| Size | 3/8 in |
| Operating Temperature Range (Fahrenheit) | -67 to 230°F |
| Operating Temperature (Celsius) | -55 to 110°C |
| Tubing Type | Wall |
| Minimum Expanded Tubing I. D. | 0.375 Inch |
| Expanded Inner Diameter | 3/8 in |
| Elongation | 4.5 |
| Agency Approvals | CSA, UL Recognized |
| Flammability Rating | UL 224 All Tubing Flame Test [jacket] |
| Package Quantity | 10 |
