Takes 2 Inserts, I6149-06-C3H, I6149-06-C5A, I6149-06R-C3H, I6149-06R-C5A Insert Compatibility, ISO 6149-1:1993, SAE J2244-1
| Port Standard Designation | ISO 6149-1:1993; SAE J2244-1 |
|---|---|
| Pilot Insert Type | Spade Blade Insert |
| Port Thread Size | M16x1.50 |
| Tube Dash Number | 6 |
| Pilot Diameter (Decimal Inch) | 0.5710 |
| Spotface Diameter (Decimal Inch) | 1.1020 |
| Shank Diameter (Inch) | 0.7870 |
| Compatible Insert Style | J1926 |
| Compatible Insert Size Code | 450H-14.5; 4C10H-14.5 |
| Number of Porting Inserts | 2 |
| Coated | Coated |
| Porting Diameter (Decimal Inch) | 0.7020 |
| Overall Length (Decimal Inch) | 3.5070 |
| Seal Angle Length | 0.102 in |
| Primary Workpiece Material | Universal |
| Primary Workpiece Material Code | P; H; K; N |
| Through Coolant | Yes |
| Porting Angle | 15 |
| Porting Angle Length (Decimal Inch) | 0.1020 |
| Head Length (Decimal Inch) | 1.8570 |
| Shank Length (Decimal Inch) | 1.6500 |
| Series | AccuPort 432 |
| UNSPSC Code | 23241603 |
| Country of Origin | UNITED STATES |
| MSC Number | MSC# 84442284 |
