Weatherproof Cover, 1 Gang, Flip-Up Cover
| Item | Weatherproof Cover |
|---|---|
| Number of Gangs | 1 Gang |
| Cover Type | Flip-Up |
| Cover Material | Copper-Free Aluminum |
| Lid Style | Self Closing |
| Mounting Orientation | Vertical |
| Standards | UL 514A |
| Height | 4-9/16 in |
| For Use With | Non-Locking Blade Plugs with 1-3/8 in Device Opening |
| Mounting Box | FS Cast Hub Device Boxes |
| Width | 2-13/16 in |
| Includes | 125V, 2 Pole, 20A, 3 Wire, 5-15R Receptacle |
| Color | Gray |
| NEMA Rating | 3R |
| Depth | 1-5/32 in |
| Features | Accurately Tapped and Tapered Threads for Tight, Rigid Joints and Ground Continuity, Gasket that Seals Around the Plug to Keep Dirt and Moisture Out |
| Receptacle Type | Single |
| NEMA Enclosure Rating | 3R |
| Housing Color | Gray |
| Current Rating | 20 A |
| Voltage Rating | 125 V AC |
| Wire Connection Type | Not Applicable |
| Housing Material | Aluminum |
| Polarized | No |
| Phase | Single |
| Wiring Method | Back |
| UL 94 Flammability Rating | Not Rated |
| Flange Type | Non-Flanged |
| Mount Type | Surface |
| Horsepower Rating | Not Applicable |
| Resistance Properties | Not Applicable |
| Number of Wires | 3 |
| Reset Type | Not Applicable |
| Flange Shape | Rectangular |
| Number of Poles | 2 |
| GFCI | No |
| Grounding | Non-Grounded |
| Hub Type | Dead End |
| Shrouded | No |
| Surge Protection | No |
| AFCI | No |
| NEMA Receptacle Configuration | 5 to 20 R |
| Connection Orientation | Straight |
| IP Rating | Not Applicable |
| Package Quantity | 1 |
