ROG Strix B550-E Gaming AMD AM4 3rd Gen Ryzen ATX Gaming Motherboard-PCIe 4.0, NVIDIA SLI, WiFi
| Promotion Restriction | Not eligible for promotion |
|---|---|
| Item | Desktop Motherboard |
| DisplayPort | Yes |
| Bluetooth | Yes |
| Number of Onboard USB 2.0 Ports | 4 |
| 2.5Gigabit Ethernet | Yes |
| RAID Supported | Yes |
| Memory Technology | DDR4 SDRAM |
| Processor Socket | Socket AM4 |
| Number of Network (RJ-45) Ports | 1 |
| Number of USB 3.2 Ports | 3 |
| RAID Levels | 0, 1, 10 |
| Total Processor Supported | 1 |
| Number of PCI Express x1 Slots | 2 |
| Number of PCI Express x16 Slots | 3 |
| Number of Onboard USB 3.2 Ports | 3 |
| Wireless LAN | Yes |
| Number of Memory Slots | 4 |
| Wireless LAN Standard | IEEE 802.11 a/b/g/n/ac/ax |
| Number of USB 2.0 Ports | 5 |
| HDMI | Yes |
| Includes | User's Manual, (4) SATA 6Gb/s cable(s), (1) Supporting DVD, (1) ROG Strix stickers, (1) Cable ties pack(s), (1) Extension Cable for RGB strips (80 cm), (1) Extension cable for Addressable LED, (1) ROG Thank you card, (1) Wi-Fi moving antenna, (1) M.2 SSD screw package(s), (1) M.2 Rubber Package(s), (1) ROG audio USB Type-C® cable, (1) ROG key chain. |
| Number of SATA Interfaces | 6 |
| Brand Compatibility | AMD |
| Processor Supported | Ryzen 7, Ryzen 3 PRO, Ryzen 9 PRO, Ryzen 9, Ryzen 5 Pro, Ryzen 3, Ryzen 7 PRO, Ryzen 5 |
| Controller Type | Serial ATA, 600 |
| Number of PCI Express Slots | 5 |
| Multi-GPU Supported | CrossFireX, SLI |
| Number of USB Ports | 8 |
| Number of Expansion Slots | 5 |
| Memory Form Factor | DIMM, UDIMM |
| Audio Channels | 7.1 |
| Max. Memory Supported | 128 GB |
| Number of M.2 Interfaces | 2 |
| Memory Speed Supported | 4400 MHz, 4600 MHz, 3000 MHz, 2400 MHz, 3200 MHz, 2800 MHz, 3600 MHz, 4000 MHz, 5100 MHz, 4133 MHz, 4266 MHz, 3866 MHz, 4800 MHz, 3466 MHz, 2133 MHz, 2666 MHz |
| Features | Environmentally Friendly |
| Onboard Video | CPU Dependent Video |
| Number of Onboard USB Ports | 7 |
| Chipset Model | B550 |
| Multi GPU Supported | CrossFireX, SLI |
| Package Contents | Strix B550-E GAMING Desktop Motherboard, User's Manual, 4 x SATA 6Gb/s cable(s), 1 x Supporting DVD, 1 x ROG Strix stickers, 1 x Cable ties pack(s), 1 x Extension Cable for RGB strips (80 cm), 1 x Extension cable for Addressable LED, 1 x ROG Thank you card, 1 x Wi-Fi moving antenna, 1 x M.2 SSD screw package(s), 1 x M.2 Rubber Package(s), 1 x ROG audio USB Type-C® cable, 1 x ROG key chain |
| Country of Origin (subject to change) | China |
| Package Quantity | 1 |
