Heating Blanket, Hazardous-Area, 120V, 180W, 6"W x 12"L, PSA, T3
| Max. Temp. | 450 deg F |
|---|---|
| Features | Chemical Resistant, Moisture Resistant, Radiation Resistant |
| Wattage | 180 W |
| Temp. Range (C) | -51 to 204 deg |
| Voltage | 120 V |
| Heating Device Outer Material | Silicone Rubber |
| Heating Device Type | Blanket |
| Amps | 1.5 |
| Width | 6 in |
| Series | SRX |
| Standards | CE, FM Approved, REACH, RoHS |
| Item | Heating Blanket |
| Temp. Range | -60 to 450 deg F |
| Includes Controller | No |
| Length | 12 in |
| Temp. Range (F) | -60 Degrees to 450 Degrees F |
| Power Cord Length | 12 in |
| Exposure Temperature - Maximum | 204 deg C |
| Exposure Temperature - Minimum | -51 Degrees C |
| Color | Orange |
| Current | 1.5 A |
| Includes Adhesive Backing | Adhesive |
| Overall Width | 6 in |
| Overall Length | 12 in |
| For Material | Metal |
| Includes Grounded Wire | Grounded |
| Product Type | Heating Blanket |
| Controller Required | Controller Required |
| Operating Temperature - Minimum | -51 deg C |
| Compatible Product Type | Conveyors, Hoppers, Silos, Tanks |
| Operating Temperature - Maximum | 232 deg C |
| Power Density | 2.5 W/sq in |
| Thickness | 3/16 in |
| Compatible with Manufacturer Model Number | TB111N-325 |
| Country of Origin (subject to change) | United States |
| Package Quantity | 1 |
