IEC Pin and Sleeve Device, Female Mechanically Interlocked Receptacle, 30A 125/250V AC
| Type | Receptacle |
|---|---|
| Material | Composite |
| Application | High Ampacity Connections |
| Color | Orange |
| Wire Size | #12 AWG to #8 AWG |
| Number Of Poles | 3-Pole |
| Connectivity | Pressure Terminal Screws |
| Material - Mounting Hardware | Screw Mounting |
| Number Of Wires | 4-Wire |
| Nema Rating | Non-NEMA |
| Item Type | Mechanically Interlocked Single |
| Wattage | 25000 W |
| Voltage Rating | 125/250 V |
| Series | Non-Fused Interlocks |
| Amperage Rating | 30 A |
| Package Quantity | 1 |
