Ceramic Fuse, AAO Series, Fast-Acting, 10A, 550V AC, 80kA at 550V AC
| Series | AAO |
|---|---|
| Speed | Fast-Acting |
| Amps | 10A |
| AC Voltage Rating | 550V AC |
| Visual Indication | Non-Indicating |
| Interrupt Rating | 80kA at 550V AC |
| Body Style | Bolt-On |
| Diameter | 14.5 mm |
| Length | 85 mm |
| Body Material | Ceramic |
| Equivalent Brand and Series | Bussmann AAO |
| DC Voltage Rating | Not Rated |
| Item | Ceramic Fuse |
| Rejection / Nonrejection | Nonrejection |
| Length (Straight Wireway) | 85 mm |
| Weight | 0.0046 lb |
| Equivalent Series | AAO |
| Element | Single |
| Standards | BS88 & IEC Part 1 & 2, CE, IEC 60269-1 |
| Fuse Speed | Fast Acting |
| Green Environmental Attribute | RoHS 2011/65/EU Compliant |
| Package Quantity | 1 |
