Ceramic Fuse, BAO Series, Fast-Acting, 40A, 500V AC, 80kA at 550V AC
| Series | BAO |
|---|---|
| Speed | Fast-Acting |
| Amps | 40A |
| AC Voltage Rating | 500V AC |
| Visual Indication | Non-Indicating |
| Interrupt Rating | 80kA at 550V AC |
| Body Style | Bolt-On |
| Diameter | 21 mm |
| Length | 7.087 in |
| Body Material | Ceramic |
| Item | Ceramic Fuse |
| Length (Straight Wireway) | 87 mm |
| Weight | 0.1173 lb |
| Element | Single |
| Standards | BS88 & IEC Part 1 & 2, CE, IEC 60269-1 |
| Fuse Speed | Fast Acting |
| Package Quantity | 1 |
