Solar Fuse, PV-1P Series, 15A, Fast-Acting, Not Rated, Cylindrical
| Item | Solar Fuse |
|---|---|
| Series | PV-1P |
| Amps | 15A |
| Speed | Fast-Acting |
| AC Voltage Rating | Not Rated |
| DC Voltage Rating | 1,000V DC |
| Body Style | Cylindrical |
| Visual Indication | Non-Indicating |
| Interrupt Rating | 33kA at 1000V DC |
| Body Material | Ceramic |
| Diameter | 9/32 in |
| Length | 1-1/2 in |
| Equivalent Brand and Series | Bussmann PV-1P, Littelfuse SPF-XR |
| Equivalent Series | PV-1P, SPF-XR |
| Fits Fuse Block Style | Non-Rejection |
| Indicating / Nonindicating | Nonindicating |
| Fuse Speed | Fast Acting |
| Class | gPV/UL PV |
| Standards | CCC (1-15A), CSA, IEC 60269-6, UL 2579 (File number E335324) |
| Green Environmental Attribute | RoHS 2011/65/EU Compliant |
| Element | Single |
| Rejection / Nonrejection | Nonrejection |
| Weight | 12.1 g |
| Package Quantity | 1 |
