Solar Fuse, PV-T Series, 10A, Fast-Acting, Not Rated, Bolt-On
| Item | Solar Fuse |
|---|---|
| Series | PV-T |
| Amps | 10A |
| Speed | Fast-Acting |
| AC Voltage Rating | Not Rated |
| DC Voltage Rating | 1,000V DC |
| Body Style | Bolt-On |
| Visual Indication | Non-Indicating |
| Interrupt Rating | 33kA at 1000V DC |
| Body Material | Ceramic |
| Diameter | 7/16 in |
| Length | 2-23/64 in |
| Equivalent Brand and Series | Bussmann PV-T |
| Equivalent Series | PV-T |
| Fits Fuse Block Style | Non-Rejection |
| Fuse Speed | Fast Acting |
| Indicating / Nonindicating | Nonindicating |
| Standards | CCC (1-15A), CSA, IEC 60269-6, UL 2579 (File number E335324) |
| Class | gPV/UL PV |
| Element | Single |
| Rejection / Nonrejection | Nonrejection |
| Green Environmental Attribute | RoHS 2011/65/EU Compliant |
| Weight | 11.7 g |
| Package Quantity | 1 |
