RLP1110, RSL1500 Imperial or Metric Cassette, 1 5/8 in. / 41 mm Hexagon AF Size
| Promotion Restriction | Not eligible for promotion |
|---|---|
| Item | Torque Wrench Cassette |
| Max. Torque | 1,408 ft-lb |
| Weight | 3 lb |
| Torque Range | 141 to 1,408 ft-lb |
| Drive Unit Model Number | 55PP55 (Mfr. No. RSL1500) |
| Nose Radius | 1.31 in |
| Application | Torque |
| Series | RLP |
| Width | 1-1/4 in |
| Material | Steel |
| For Use With | Enerpac RSL Series Hydraulic Torque Wrenches |
| Nominal Torque @ 10,000 PSI (Nm) | 1,909 |
| Hex Size | 1-5/8 in |
| Nominal Torque @ 10,000 PSI (ft.-lb.) | 1,408 |
| Socket Shape | Hex |
| Nominal Torque (ft-lb) @ 10,000 psi | 1,408 ft-lb |
| Minimum Hex Size (mm) | 41 mm |
| Tool Weight | 3 lb |
| Maximum Hex Size (mm) | 41 mm |
| Compatible Manufacturer Drive Unit Number | RSL11000 |
| Product Type | Torque Wrench Cassette |
| Minimum Hex Size (in) | 1-5/8 in |
| Tool Width | 1-1/4 in |
| Compatible Tool Series | Hydraulic Torque Wrench Drive |
| Tool Height | 4-7/8 in |
| Tool Series | RLP |
| Maximum Hex Size (in) | 1-5/8 in |
| Nominal Torque (N-m) @ 10,000 psi | 1,909 N-m |
| Max. Pressure | 10000 psi |
| Package Quantity | 1 |
