Molded Case Circuit Breaker, TJJ Series, 400A, 2 Pole, 600V AC, 14kA at 277/480V AC
| Item | Molded Case Circuit Breaker |
|---|---|
| Series | TJJ |
| Amps | 400A |
| Number of Poles | 2 |
| AC Voltage Rating | 600V AC |
| Circuit Breaker Type | Standard |
| Phase | 1 |
| Circuit Breaker Actuator | Toggle |
| Circuit Breaker Mounting Style | Bolt On |
| Max. AIR Rating | 14kA at 277/480V AC |
| Trip Type | Thermal Magnetic |
| Instantaneous Trip | Fixed |
| Terminal Connection | Line, Load Lug |
| Phase Connection | Not Applicable |
| Frame Size | 600A/TJJ |
| Width | 8-1/4 in |
| Depth | 5.38 in |
| Height | 10.13 in |
| DC Voltage Rating | 250V DC |
| Max. Wire Size | 250 MCM (Al), 600 MCM (Cu) |
| High Amp Trip Setting | 4,000 A |
| Low Amp Trip Setting | 1,200 A |
| For Use With | GE Panelboards |
| Min. Wire Size | 2 AWG (Al), 6 AWG (Cu) |
| Standards | CSA Certified, UL Listed |
| Mounting | Bolt On Panelboard |
| Package Quantity | 1 |
