Weldon Flat & Flange Shank, Uses TPHT 080305 Inserts, Series GT
| Compatible Drill Style | GT |
|---|---|
| Maximum Drill Diameter (mm) | 16.00 |
| Maximum Drill Diameter (Decimal Inch) | 0.6300 |
| Maximum Drill Depth (Decimal Inch) | 55.4400 |
| Maximum Drill Depth (mm) | 1419.86 |
| Shank Type | Flange; Weldon Flat |
| Shank Diameter (Inch) | 1 |
| Shank Diameter (Decimal Inch) | 1.0000 |
| Number of Drill Inserts | 1 |
| Cutting Direction | Right Hand |
| Maximum Drill Depth Range (Decimal Inch) | 10.0000+ |
| Tool Material | Steel |
| Compatible Insert Style | TPHT |
| Compatible Insert Size Code | 080305 |
| Drill Depth by Diameter Ratio | 88xD |
| Coolant Entry Style Code | 1-Axial Concentric Entry |
| Overall Length (Decimal Inch) | 59.1400 |
| Series | GT |
| Flute Length (Decimal Inch) | 55.4400 |
| Flute Length (mm) | 1419.86 |
| Body Length (mm) | 1443.99 |
| Body Length (Decimal Inch) | 59.0600 |
| Shank Length (Decimal Inch) | 2.7600 |
| Shank Length (mm) | 70.10 |
| Tool Application | Drilling |
| Tool Performance | General Purpose |
| Insert Size (Decimal Inch) | 0.3370 |
| UNSPSC Code | 23291503 |
| Insert Compatibility | TPHT080305R-DT |
| Insert Lock Screw | SR14-560/S |
| Coolant Through | Yes |
| undefined | undefined |
| MSC Number | MSC# 97025498 |
