Uses (2) Q;S;XOMT-HQ Inserts, 70 mm OAL
| Cutting Diameter (mm) | 14.00 |
|---|---|
| Overall Length (mm) | 70.00 |
| Maximum Depth of Cut (mm) | 5.80 |
| Cutter Style | E90X |
| Shank Type | Weldon Flat |
| Shank Diameter (mm) | 16.00 |
| Insert Holding Method | Screw |
| Tool Material | Solid Carbide |
| Series | Heliquad |
| Lead Angle | 90 |
| Shank Length (mm) | 70.00 |
| Tool Application | Milling |
| Standards | ISO 9001:2008; AS 9100; OSHAS18001:2007; ISO 50001; ISO 14001:2004 |
| Insert Compatibility | Q; S; XOMT-HQ |
| UNSPSC Code | 27112803 |
| Usable Length (mm) | 22.00 |
| Number Of Flutes | 2 |
| Number Of Cutter Inserts | 2 |
| Coolant Through | No |
| Country of Origin | Israel |
| MSC Number | MSC# 08401390 |
