Uses (1) Insert, 80 mm OAL
| Cutting Diameter | 0.4724 in |
|---|---|
| Cutting Diameter (mm) | 12.00 |
| Overall Length (Decimal Inch) | 3.1496 |
| Overall Length (mm) | 80.00 |
| Maximum Depth of Cut (mm) | 10.00 |
| Maximum Depth of Cut (Decimal Inch) | 0.3937 |
| Cutter Style | HM90 E90A-10 |
| Shank Type | Cylindrical |
| Shank Diameter (Decimal Inch) | 0.6299 |
| Shank Diameter (mm) | 16.00 |
| Insert Holding Method | Screw |
| Maximum Ramping Angle | 32 |
| Tool Material | Solid Carbide |
| Series | Heli2000 |
| Lead Angle | 90 |
| Shank Length (mm) | 60.00 |
| Head Length (Decimal Inch) | 0.7874 |
| Head Length (mm) | 20.00 |
| Maximum RPM | 91850 |
| Tool Application | Milling |
| Standards | ISO 9001:2008; AS 9100; OSHAS18001:2007; ISO 50001; ISO 14001:2004 |
| UNSPSC Code | 27112803 |
| Usable Length (mm) | 14.00 |
| Number Of Cutter Inserts | 1 |
| Coolant Through | No |
| Country of Origin | Israel |
| MSC Number | MSC# 05432166 |
