Uses (6) HP ANK-07.. Inserts, 3-1/2" OAL
| Cutting Diameter | 3/4 |
|---|---|
| Overall Length (Decimal Inch) | 3.5000 |
| Overall Length (Inch) | 3-1/2 |
| Maximum Depth of Cut (Decimal Inch) | 0.8500 |
| Cutter Style | HP ANK-07 |
| Shank Type | Weldon Flat |
| Shank Diameter (Decimal Inch) | 0.7500 |
| Shank Diameter (Inch) | 3/4 |
| Insert Holding Method | Screw |
| Tool Material | Solid Carbide |
| Series | Heliplus |
| Lead Angle | 90 |
| Shank Length (Decimal Inch) | 2.2500 |
| Head Length (Decimal Inch) | 1.25 |
| Tool Application | Milling |
| Standards | ISO 9001:2008; AS 9100; OSHAS18001:2007; ISO 50001; ISO 14001:2004 |
| Rake | Positive |
| Insert Compatibility | HP ANK-07.. |
| UNSPSC Code | 27112803 |
| Number Of Flutes | 2 |
| Number Of Cutter Inserts | 6 |
| Coolant Through | No |
| Country of Origin | Israel |
| MSC Number | MSC# 91149823 |
