304.80 mm OAL, Screw, Uses TP.. Inserts
| Minimum Bore Diameter (mm) | 30.48 |
|---|---|
| Minimum Bore Diameter (Decimal Inch) | 1.2000 |
| Toolholder Style | E-STLP |
| Tool Material | Solid Carbide |
| Insert Compatibility | TP.. |
| Shank Diameter (mm) | 25.40 |
| Hand of Holder | Left Hand |
| Shank Diameter (Inch) | 1 |
| Overall Length (Decimal Inch) | 12.0000 |
| Overall Length (mm) | 304.80 |
| Insert Holding Method | Screw |
| Rake | Neutral |
| Rake Angle | 0.00 |
| Lead Angle | 5 |
| Insert Inscribed Circle (Inch) | 3/8 |
| Multi-use Tool | No |
| Back of Bar to Cutting Edge (Decimal Inch) | 0.6400 |
| Center to Cutting Edge (Decimal Inch) | 0.6400 |
| UNSPSC Code | 23241601 |
| Insert Thickness (Inch) | 5/32 |
| Coolant Hole Diameter (Decimal Inch) | 0.3120 |
| Coolant Through | Yes |
| Country of Origin | UNITED STATES |
| undefined | undefined |
| MSC Number | MSC# 48594139 |
