Uses 7 LNGU15T608SRGE Inserts, Series MILL 4-15
| Maximum Cutting Diameter (Decimal Inch) | 2.4800 |
|---|---|
| Maximum Cutting Diameter (mm) | 63.00 |
| Maximum Depth of Cut (mm) | 15.50 |
| Maximum Depth of Cut (Decimal Inch) | 0.6100 |
| Arbor Hole Diameter (mm) | 22.00 |
| Arbor Hole Diameter (Decimal Inch) | 0.8670 |
| Compatible Insert Size Code | LNGU15T608SRGE |
| Lead Angle | 0 |
| Series | MILL 4-15 |
| Overall Height (Decimal Inch) | 1.5740 |
| UNSPSC Code | 27112803 |
| Number Of Cutter Inserts | 7 |
| Country of Origin | UNITED STATES |
| MSC Number | MSC# 30642359 |
