Milling Insert, Pentagon, PNEU 1205ANERW PR1535 Grade PVD Carbide
| Item | Parallelogram Milling Insert |
|---|---|
| Insert Style | PNEU |
| Insert Size | 1,205 |
| Chip-Breaker | Yes |
| Mounting Hole Dia. | 6.2 mm |
| Rake | Positive |
| Cutting Direction | Right Hand |
| ISO Number | PNEU1205ANER-W |
| Features | 8.10mm Wiper Edge Length, For Precipitation-Hardened Stainless Steel, For Titanium Alloys and Precipitation-Hardened Stainless Steel |
| Thickness | 5.56 mm |
| Cutting Edge Length | 17.85 mm |
| Material - Machining | Carbide |
| For Toolholder | MFPN45...R |
| Insert Holding Type | Screw Held |
| Primary Material Application | Stainless Steel |
| Wiper Insert | Yes |
| ANSI Code | PNEU1205ANERW |
| Manufacturer Grade | PR1535 |
| Secondary Material Application ISO Code | M, S, P |
| Secondary Material Application | Austenitic Stainless Steel, Carbon and Alloy Steel, Free-Cutting Steel, High-Temperature Alloys, Martensitic Stainless Steel, Mold Steel |
| Cutting Application | Chamfering, Facing |
| Shape | Pentagon |
| Through Hole Inside Dia. | 6.2 mm |
| Measurement System | Metric |
| Coating Process | PVD |
| Hole Type | Screw Hole |
| Cutting Edge | Honed |
| Primary Material Application ISO Code | M |
| Number of Cutting Edges | 2 |
| Chip-Breaker Code | ANER-W |
| Finish - Machining | Megacoat Nano |
| Package Quantity | 1 |
