Raceway, 6000 Series, 1 Channel, 4 3/4 in W, 3 9/16 in H, 10 ft L, Gray
| Item | Raceway |
|---|---|
| Color | Gray |
| Finish | Scuffcoat |
| Material | Steel |
| Length | 10 ft |
| Cover Type | Snap On |
| Number of Channels | 1 |
| Connector Type | Back End, Entrance End |
| Height | 3-9/16 in |
| Series | 6000 |
| Width | 4-3/4 in |
| Standards | PEP |
| Mounting Style | Screw On |
| Length (Straight Wireway) | 10 ft |
| Knockouts | (2) 9/32 in Trade Size |
| Mounting | Screw |
| Material of Construction | Steel |
| Length (In.) | 120 |
| Height (In.) | 4 |
| Width (In.) | 4-3/4 |
| Basic Material | Steel |
| Depth | 3-1/2 in |
| Features | The Wiremold 6000 Series Raceway can be used divided for separate wiring circuits or multi-service applications. For large cabling installations, 6000 can be used undivided as headers and feeders or to bring wiring to a specified location. 6000 Series Raceway is ideal for all applications requiring a high cable capacity, dual service steel raceway. Commercial, institutional, and industrial applications all benefit from the 6000 Series rigid steel construction and durable Ivory ScuffCoat finish. 6000 Series Raceway is also ideal for municipalities that require either all steel construction or prohibit nonmetallic cable management systems. |
| Voltage | 600 V |
| Special Features | Extra Large Capacity, Complete line of fittings, Wide range of Datacom connectivity options, UL5 and ADA compliant, UL and cUL Listed |
| Type | Raceway |
| Standard | cULus Listed Surface Metal Raceway: File E4376: Guide RJBT/RJBT7 |
| Application Sector | Commercial |
| Cable Manager Type | Raceway Base |
| Product Series | 6000 |
| Product Type | Cable Routing |
| Product Material | Steel |
| Product Name | 6000 Raceway Base |
| Product Color | Gray |
| cULus Listed | Yes |
| Product Line | Wiremold |
| Product Height US | 4-3/4 in |
| Product Volume US | 1,995 cu in |
| Product Width US | 120 in |
| Product Environmental Profile | Yes |
| Product Depth US | 3-1/2 in |
| Package Quantity | 1 |
