Acrylic Adhesive, E-30CL Series, Light Amber, (1) 0.34 oz, (1) 1.41 oz, Bottle, 2:01 Mix Ratio
| Item | Acrylic Adhesive |
|---|---|
| Type | Medium Work Life |
| Application | Bonding |
| Color | Amber |
| For Use On | 983439, Mfr. No. 983438 |
| Container Size | 0.34 fl oz, 1.41 fl oz |
| Container Type | Bottle |
| Functional Cure | 3 hr |
| Full Cure | 24 hr |
| Mixing Ratio | 2:01 |
| Shear Strength | 3,100 psi |
| Temp. Range | -65 to 250 deg F |
| Working Time | 30 min |
| Series | E-30CL |
| Epoxy Max. Temp | 250 to 299 deg F |
| Epoxy Color | Clear |
| Size | 13.53 fl oz |
| Includes | Hardener and Wooden Mixing Stick, Resin |
| Temp. Range (F) | -65 to 250 |
| Shear Strength (PSI) | 3,100 |
| For Use With | 983439, Mfr. No. 983438 |
| Work Life | 30 min |
| Structural Adhesive Type | Epoxy Adhesive |
| Epoxy Container | Dual-Cartridge |
| Standards | ASTM E1640, ISO 11359-2, ISO 1675, ISO 4587, ISO 527-2, ISO 868 |
| Resin Type | Epoxy |
| Application Method | Two-Part Dispenser |
| Cure Method | Ambient |
| Non-Sagging | No |
| Compatible Applicator (Grainger Part Number) | 61LA03 |
| Marine Grade | No |
| Compatible Applicator | 218311; 983438 |
| Tensile Strength | 8,000 psi |
| Primary Applications | General Purpose |
| Minimum Performance Temperature | -65 deg F |
| Hardness at Full Cure | 80 to 90 Shore D |
| Interior/Exterior | Interior Only |
| Included Components | Hardener, Resin |
| Water Resistance | Not Water-Resistant |
| Resin Color | Clear |
| VOC Content Weight Percentage | Less Than 1% |
| Low Odor | No |
| Materials Bonded | Ceramic, Glass, Metal, Plastic |
| Maximum Viscosity | 10,000 cps |
| Maximum Performance Temperature | 250 deg F |
| Total Volume | 400 mL |
| Cured Color | Clear |
| VOC Content Weight | Less than 10 g/L |
| Full Cure Time | 24 hr |
| Alternate Product Name | E-30CL |
| Minimum Viscosity | 10,000 cps |
| Features | Impact Resistant, Mechanical and Electrical Insulating Properties, Optical Clarity |
| Hardener Color | Clear |
| Container Type - Adhesives | Dual-Cartridge |
| Compatible Mixer Tip | 45VG49 |
| Country of Origin (subject to change) | United States |
| Package Quantity | 1 |
