Glass Fuse, GDL Series, Time-Delay, 20A, 32V AC, 300A at 32V AC, 5 PK
| Series | GDL |
|---|---|
| Speed | Time-Delay |
| Amps | 20A |
| AC Voltage Rating | 32V AC |
| Visual Indication | Glass Fuse |
| Interrupt Rating | 300A at 32V AC |
| Body Style | Cylindrical |
| Diameter | 1/4 in |
| Length | 1-1/4 in |
| Body Material | Glass |
| Equivalent Brand and Series | Bussmann MDL, Bussmann MDQ, Bussmann MDV, Bussmann MDX, Littelfuse 313, Littelfuse 315, Mersen GDL, Mersen GDV |
| Fits Fuse Block Style | Nonrejection |
| DC Voltage Rating | Not Rated |
| Item | Glass Fuse |
| Equivalent Series | 313, 315, GDL, GDV, MDL, MDQ, MDV, MDX |
| Element | Single |
| Standards | CSA, UL |
| APPROVALS & STANDARDS | 1/16A through 8A, 250VAC, UL Listed and CSA Certified; 10A through 15A, 125VAC, UL Listed and CSA Certified; 20A through 30A, 32VAC, UL Listed to U.S. and Canadian safety standards |
| Green Environmental Attribute | RoHS 2011/65/EU Compliant |
| Mounting | Clip |
| Fuse Class | Supplemental |
| Connection/Terminal Type | Ferrule |
| Short Description | Fuse GDL - Time-Delay 32V 20A 6x32mm, 1/4" X 1-1/4" |
| APPLICATIONS | Electronic circuits |
| Body/Insulating Material | Glass |
| Item Description (ERP) | 32V 20A 1/4 X 1-1/4 FUSE |
| Functionally Equal To | Bussmann MDL, MDQ, MDV, MDX, Littelfuse 313, 315, Mersen/Ferraz Shawmut GDV |
| Connection Type | Ferrule |
| Package Quantity | 5 |
