Terminal de compresión de aluminio, 2 orificios, calibre 4/0 AWG, 1/2 pulgadas (12.7mm), LAB4/0-12-5R.
| Length | 3 in |
|---|---|
| Color Code | White |
| Includes | Connector barrel pre-filled with oxide inhibiting joint compound |
| Features | Corrosion Resistant |
| Aluminum Conductor Size (AWG) | 36,617 |
| Tongue Type | Standard |
| Barrel Length (In.) | 1-3/4 |
| Panduit Die Index Number | P66 |
| Wire Strip Length (In.) | 1.75 |
| Maximum Voltage (kV) | 35 |
| UL Temperature Rating (°C) | 90 |
| Tongue Width (In.) | 1.19 |
| Tongue Thickness (In.) | 0.31 |
| Burndy Die Index Number | 298 |
| Tongue Width (mm) | 30.226 |
| Barrel Type | Standard Barrel |
| Tongue Angle | Straight |
| Barrel Length (mm) | 44.45 |
| Finish/Coating | Tin-Plated |
| Stud Hole Size (mm) | 12.7 |
| Stud Hole Spacing (In.) | 1.75 |
| Standards Met | cULus listed |
| Product Type | Compression Connectors - Lugs |
| Stud Hole Spacing (mm) | 44.45 |
| Base Material | Aluminum |
| Tongue Thickness (mm) | 7.874 |
| T & B Die Index Number | 66 |
| Wire Strip Length (mm) | 44.45 |
| Stud Hole Size (In.) | 1 to 2 |
| Copper Code Conductor Size (AWG) | 36,617 |
| Connector Plating | Tin |
| Product Material | Aluminum |
| Connector Details | 1 x Terminal |
| Product Name | Terminal Connector |
| Product Class | Wire Termination |
| Package Quantity | 1 |
