DIN Rail Wiring Duct, Lead-Free PVC, 6.22" x 2.12" x 1' (6-Pack), White
| Item | DIN Rail Wiring Duct |
|---|---|
| Color | White |
| Material | Lead-Free PVC |
| Width | 6.22 in |
| Height | 2.12 in |
| Includes | Cover |
| Overall Length | 1.8 m |
| Application | Creating Valuable Panel Space Savings, Providing Easier Installation and Maintenance, and Improving Reliability |
| Measurement System | Imperial |
| Cover Part Number | DRDC2WH6 |
| Overall Height (mm) | 53.8 |
| Overall Length (ft.) | 6 |
| Wiring Duct Type | DRD |
| Flammability Rating | UL94 V-0 |
| Note | 2-Channel Wiring duct with a hinged and flexible cover that allows you to mount DIN Rail and components on top of the duct to maximize space. Up to 30% panel Space savings, up to 25% material cost savings, and up to 50% faster installation. Pass thru holes to shorten the wire path |
| Overall Width (In.) | 6.22 |
| Overall Width (mm) | 158 |
| Mount Method | Mounting Holes |
| Slot Width (mm) | 7.9 |
| Overall Length (m) | 1.8 |
| Product Type | Base, Cover |
| Wiring Duct Style | DIN Rail Wiring Duct |
| Overall Height (In.) | 2.12 |
| Slot Width (In.) | 0.31 |
| Product Class | Wire Routing, Management & Protection |
| Package Quantity | 6 |
