Non-Shrink PVC Tubing, 0.50"x500ft, 600V
| Item | Non-Shrink PVC Tubing,0.50"x500ft,600V |
|---|---|
| Material | Polyvinyl Chloride |
| Color | Black |
| Application | 1) Provides Insulation and Protection for Lead Wires, Wire Harness Assemblies, Soldered Joints and Components in Electrical and Electronic Equipment, 2) All Purpose Flexible and Non-Shrinkable |
| Overall Length | 152.4 m |
| Overall Length (m) | 152.4 |
| Minimum Operating Temperature (°C) | -20 |
| Resistance Properties | Oil-Resistant |
| Overall Length (ft.) | 500 |
| Maximum Voltage (V) | 600 |
| Nominal Diameter (mm) | 13.3 |
| Maximum Operating Temperature (°C) | 105 |
| Minimum Operating Temperature (°F) | -4 |
| Maximum Operating Temperature (°F) | 221 |
| Inside Diameter (In.) | 0.52 |
| Inside Diameter (mm) | 13.3 |
| Nominal Diameter (In.) | 0.524 |
| Product Type | Tubing |
| Wall Thickness (mm) | 0.6 |
| Wall Thickness (In.) | 0.035 |
| Max Operating Temperature | 105 degrees celsius |
| Min Operating Temperature | -20 degrees celsius |
| Product Class | Wire Routing, Management & Protection |
| Package Quantity | 1 |
