Screw, Uses 6 Inserts, RD Inserts, 6 Tooth, Straight Teeth
| Connection Type | Combimaster |
|---|---|
| Maximum Depth of Cut (Decimal Inch) | 0.4090 |
| Maximum Depth of Cut (mm) | 10.39 |
| Cutter Diameter (Decimal Inch) | 2.0000 |
| Cutter Diameter (Inch) | 2 |
| Cutting Direction | Right Hand |
| Insert Holding Method | Screw |
| Number Of Cutter Inserts | 6 |
| Compatible Insert Style | RD |
| Compatible Insert Size Code | 0803 |
| Tooth Type | Straight |
| Rake | Neutral (Axial); Neutral (Radial) |
| Series | R335.29 |
| Toolholder Style | R335.29 |
| Modular Connection Size | M16 |
| Hub Diameter (Decimal Inch) | 1.1810 |
| Hub Diameter (mm) | 30.00 |
| Maximum RPM | 20200 |
| Tool Application | Side Milling; Disc Milling |
| Tool Performance | General Purpose |
| Primary Workpiece Material | Stainless Steel; Steel |
| Primary Workpiece Material Code | P |
| Minimum Cutting Width (Decimal Inch) | 0.3150 |
| Maximum Cutting Width (Decimal Inch) | 0.3150 |
| Radius | Yes |
| Lead Angle | 90 |
| UNSPSC Code | 23241629 |
| Cutter Body Width (Decimal Inch) | 0.3150 |
| Manufacturers Catalog Number | R335.29-02.00-16RE-6N-R4 |
| Insert Inscribed Circle (mm) | 0.31 |
| Number Of Teeth | 6 |
| Coolant Through | No |
| Complete Insert Compatibility | RD..0803 |
| Country of Origin | France |
| MSC Number | MSC# 62656111 |
