Screw, Uses 4 Inserts, LNK Inserts, 8 Tooth, Staggered Teeth
| Connection Type | Arbor |
|---|---|
| Cutting Width (Inch) | 5/16 |
| Maximum Depth of Cut (Decimal Inch) | 0.7130 |
| Hole Diameter (Inch) | 1 |
| Hole Diameter (Decimal Inch) | 1.0000 |
| Cutter Diameter (Decimal Inch) | 3.0000 |
| Cutter Diameter (Inch) | 3 |
| Cutting Direction | Right Hand |
| Insert Holding Method | Screw |
| Number Of Cutter Inserts | 4 |
| Compatible Insert Style | LNK |
| Compatible Insert Size Code | 0505.. |
| Tooth Type | Staggered |
| Rake | Positive (Axial); Negative (Radial) |
| Series | R335.18 |
| Toolholder Style | R335.18 |
| Hub Diameter (Decimal Inch) | 1.8800 |
| Keyway Width (Decimal Inch) | 0.3820 |
| Maximum RPM | 10900 |
| Tool Application | Side Milling; Disc Milling |
| Tool Performance | General Purpose |
| Primary Workpiece Material | Stainless Steel; Steel |
| Primary Workpiece Material Code | P |
| Minimum Cutting Width (Decimal Inch) | 0.3120 |
| Maximum Cutting Width (Decimal Inch) | 0.3120 |
| Radius | No |
| Lead Angle | 90 |
| UNSPSC Code | 23241629 |
| Cutter Body Width (Decimal Inch) | 0.3120 |
| Manufacturers Catalog Number | R335.18-03.00-0.31F-4N |
| Number Of Teeth | 8 |
| Coolant Through | No |
| Complete Insert Compatibility | LNK.0504.. |
| Country of Origin | France |
| MSC Number | MSC# 44898120 |
