General Purpose Transformer, 1 kVA, NEMA 3R, 115°C, 110/220V AC, 190/200/208/220V, 380/400/416/440V
| Item | General Purpose Transformer |
|---|---|
| Input Voltage - Transformer | 190/200/208/220V, 380/400/416/440V |
| Mounting - Transformer | Wall |
| Hz - Electrical | 50/60 Hz |
| IP Rating | IP54 |
| Outdoor Rated - Transformer | Yes |
| Winding Material | Copper |
| Color | Gray |
| Width | 7 in |
| Standards | CSA Certified, cULus, REACH Regulation, RoHS, TUV, UL Listed |
| Temp. Rise | 115 deg C |
| Depth | 5.4 in |
| Winding Material - Transformer | Copper |
| Enclosure Rating | NEMA 3R |
| Knockout Size - Transformer | 1/2 in, 3/4 in |
| Phase - Electrical | 1 |
| VA Rating - Transformer | 1 kVA |
| Enclosure Finish | Paint |
| Enclosure Material | Steel |
| Manufacturers Warranty Length | 1 yr |
| Output Voltage - Transformer | 110/220V AC |
| Height | 8.2 in |
| Voltage Function - Transformer | Step Down |
| Includes | Not Applicable |
| Insulation Max. Temp. | 180 °C |
| Insulation Temperature | 356°F |
| Primary To Secondary Voltage | 190/200/208/220 x 380/400/416/440 V 110/220 V |
| Product Certifications | CSA, cULus, TUV, UL, Listed |
| Enclosure Code | 7A |
| Sound Level | 37 dB |
| Includes Knockouts | Knockouts Included |
| Package Quantity | 1 |
