Molded Case Circuit Breaker, LA Series, 225A, 3 Pole, 600V AC, 42kA at 240V AC
| Item | Molded Case Circuit Breaker |
|---|---|
| Series | LA |
| Amps | 225A |
| Number of Poles | 3 |
| AC Voltage Rating | 600V AC |
| Circuit Breaker Type | Standard |
| Phase | 3 |
| Circuit Breaker Actuator | Toggle |
| Circuit Breaker Mounting Style | I-Line, Plug-On |
| Max. AIR Rating | 42kA at 240V AC |
| Trip Type | Thermal Magnetic |
| Instantaneous Trip | Adjustable |
| Terminal Connection | Lug, I-Line |
| Phase Connection | ABC |
| Frame Size | 400A, LA |
| Width | 6 in |
| Depth | 5.84 in |
| Height | 11 in |
| DC Voltage Rating | 250V DC |
| Standards | CSA, UL Listed |
| High Amp Trip Setting | 2,250 A |
| For Use With | I Line Panelboards |
| Low Amp Trip Setting | 1,125 A |
| Min. Wire Size | 1/0 AWG |
| Max. Wire Size | 250 MCM, 600 MCM |
| Application | HACR rated Applications |
| Features | Mercury Free; PVC Free |
| Mounting | Plug In Panelboard |
| Package Quantity | 1 |
