Arrancador de motor NEMA, tipo S, bobina de repuesto, 550/600 VCA 50/60 Hz, 2 o 3 polos, arrancador de tamaño NEMA 2 y iluminación 8903SP.
| Item | Contactor+Starter Coil 600Vac |
|---|---|
| Width | 3.98 in |
| Depth | 2.43 in |
| Height | 2.61 in |
| Rated Operational Voltage | 600 V AC 60 Hz; 550 V AC 50 Hz |
| Product Or Component Type | coil |
| NEMA Size | 2 |
| Accessory / Separate Part Destination | Class 8502 type SD contactor; Class 8903 type SP lighting contactor |
| Inrush Power in VA | 296 VA; 311 VA |
| Average Consumption | 36 VA, 37 VA |
| [Ue] Rated Operational Voltage | 600 V AC 60 Hz, 550 V AC 50 Hz |
| Package Quantity | 1 |
