DC to DC Converter, 18-36V DC to 24V DC, 70VA, 0 Hz, DIN Rail, Metal
| Item | DC to DC Converter |
|---|---|
| Converts | 18-36V DC to 24V DC |
| VA Rating | 70 VA |
| Enclosure Material | Metal |
| Mounting | DIN Rail |
| Frequency | 0 Hz |
| Phase | Not Applicable |
| Height | 5.24 in |
| Width | 3 in |
| Depth | 1-1/2 in |
| Weight (Approximate) | 1.10 lb |
| Device Supported | Security Device, Remote Power System, Wireless Base Station |
| Maximum Output Current | 2.9 A |
| Product Series | TP-VRHP |
| Output voltage | 24 V DC |
| Package Contents | TP-VRHP-2424 DC Converter, DIN rail adapters |
| Maximum Output Power | 70 W |
| DC Input Voltage Range | +/ - 18 to 36VDC |
| Maximum Power | 70 W |
| Efficiency | >85% |
| Operating temperature | - 22°F to 149°F |
| Isolation Voltage / Ohms | 1500VDC Min. / 100M Ohms Min |
| DC Voltage Output | 24 VDC @ 2.9 A |
| Wire Gauge | 12AWG Max |
| Operating Humidity | 0 to 90% RH |
| Protections | Short Circuit, Overvoltage, Overload |
| Load / Line Regulation | 5% / 1% |
| Ripple / Noise | 2% / 5% |
| Package Quantity | 1 |
