Carbon Steel Electrical Enclosures, 6 in H, 4 in D, 4 in W, NEMA 12, Screw On
| CAD Available | Yes |
|---|---|
| Item | Electrical Enclosures |
| Nominal Width | 4 in |
| Nominal Height | 6 in |
| Nominal Depth | 4 in |
| Enclosure NEMA Rating | NEMA 12 |
| Material of Enclosure | Carbon Steel |
| Closure Method | Screws |
| Enclosure Cover Type | Screw On |
| Knockouts | Yes |
| Metallic / Non-Metallic | Metallic |
| Color | Gray |
| Finish | Polyester Powder |
| Mounting | Wall |
| Solid / Clear Cover | Solid |
| Interior Panel | 4LV58 |
| Metal Gauge | 14 ga |
| Standards | CSA Certified, cULus, UL Listed |
| Usable Opening Depth | 3.88 in |
| Gasket | Neoprene |
| Features | External Mounting Plates |
| Series | B-SC |
| Enclosure Material | Steel |
| Cover Type | Screw Cover |
| Weight | 3.56 lb. |
| Capacity | 96 cu in |
| Application | Designed for use as instrument housings, electrical control enclosures, terminal wiring boxes, or electrical junction boxes. Provides protection from dirt, dust, oil, and water. |
| Includes Knockouts | Knockouts Not Included |
| Environment - MERCH | Dust Tight |
| Compatible Panel Model Number | P0604, P0604G, P0604PP |
| Gasket Material | Neoprene |
| Cover Material Thickness | 14 ga |
| Body Material Thickness | 14 ga |
| NEMA Enclosure Rating | 12, 13 |
| Cover Style | Solid |
| Cover Closure Type | Screw On |
| Package Quantity | 1 |
