Padlockable Hasp Electrical Enclosures, 24 in H, 8 in D, 24 in W, 12, 13, Steel
| CAD Available | Yes |
|---|---|
| Item | Electrical Enclosures |
| Nominal Width | 24 in |
| Nominal Height | 24 in |
| Nominal Depth | 8 in |
| NEMA Enclosure Rating | 12, 13 |
| Enclosure Material | Steel |
| Closure Method | Hasp |
| Cover Closure Type | Hinged |
| Knockouts | No |
| Metallic / Non-Metallic | Metallic |
| Color | Gray |
| Finish | Polyester Powder |
| Mounting | Wall |
| Cover Style | Solid |
| Enclosure Cover Type | Hinged |
| Enclosure NEMA Rating | NEMA 12 |
| Metal Gauge | 14 ga |
| Solid / Clear Cover | Solid |
| Series | N12 |
| Features | External Mounting Feet |
| Material of Enclosure | Carbon Steel |
| Interior Panel | 2W829 |
| Gasket | Seamless Polyurethane Poured in Place |
| Usable Opening Depth | 7.88 in |
| Standards | CSA Certified, cULus, UL Listed |
| Cover Type | Door |
| Application | Intended for use in housing electrical and electronic controls, instruments, components and associated wiring. These enclosures incorporate hinged doors which provide convenient access. Designed for indoor use in protecting components from dust, dirt, oil and water. |
| Environment - MERCH | Dust Tight |
| Gasket Material | Seamless Polyurethane Poured in Place |
| Compatible Panel Model Number | NP2424, NP2424G |
| Includes Knockouts | Knockouts Not Included |
| Body Material Thickness | 14 ga |
| Package Quantity | 1 |
