Mc 8P M/Mp 0.3M #22-7 #18-1 Yel Pvc
Traducción: Cable de 8 pares de 0.3 metros, con calibre #22-7 y #18-1, color amarillo de PVC.
| Cable Length | 0.3 m |
|---|---|
| Series | 130007 |
| Type | Single Ended |
| Keyway | Single |
| IP Rating | IP67 |
| UL | E152210 |
| Material - Coupling Nut | Anodized Aluminum |
| Material - Contact | Copper Alloy |
| Orientation | Straight to Pigtail |
| Wire Size (AWG) | 18, 22 |
| Cable Diameter | 7.36 mm |
| Product Name | Mini-Change |
| Material - Plating Mating | Gold |
| Connector End A | Mini-Change |
| Current - Maximum per Contact | 2.5 A |
| Material - Connector Body | TPE |
| Voltage - Maximum | 300 V |
| Connector End B | Pigtail |
| Protocol | DeviceNet |
| Gender | Male-Pigtail |
| Temperature Range - Operating | -20° to +90°C |
| Material - Cable Jacket | PVC |
| Poles | 8 |
| Wire/Cable Type | AWM 2661 |
| Coupling Style | Threaded |
| CSA | LR6837 |
| Color - Cable Jacket | Yellow |
| LED Indicator | No |
| Package Quantity | 1 |
