Product Description
The Schneider Electric 170ADI35000 is a discrete input base module from the Modicon Momentum range. This module is designed for distributed control architecture with a discrete input voltage of twenty-four volts DC. It contains two groups of sixteen inputs, conforming to IEC 1131-2 type one with positive discrete input logic. The isolation between channels and ground is five hundred volts AC. The module features thirty-two LEDs for signaling channel status. It has dimensions of one hundred twenty-five millimeters by forty-seven point five millimeters by one hundred forty-one point five millimeters and a weight of zero point two kilograms. Major applications of this module include infrastructure and energy management, material handling, and simple machine control. The product meets certification standards, including CE, CSA, and UL, and is suitable for wall mounting.
Discrete input base for distributed control
Features thirty-two channel status LEDs
Certified by CE, CSA, and UL
Product Highlights
Part of the flexible Modicon Momentum system, allowing for versatile control applications and easy snap-together installation.
Product Information
Standard Information
Brand: Schneider Electric
Manufacturer: Square-D / Schneider
Technical Specifications
MPN: 170ADI35000
Depth: 47.5 mm
Width: 125 mm
Height: 141.5 mm
Weight: 0.2 kg
Current: 250 mA
Power Supply: 24 VDC
Response Time: 2.2 ms (state 0 to state 1), 3.3 ms (state 1 to state 0)
Product DescriptionThe Schneider Electric 170ADI35000 is a discrete input base module from the Modicon Momentum range. This module is designed for distributed control architecture with a discrete input voltage of twenty-four volts DC. It contains two groups of sixteen inputs, conforming to IEC 1131-2 type one with positive discrete input logic. The isolation between channels and ground is five hundred volts AC. The module features thirty-two LEDs for signaling channel status. It has dimensions of one hundred twenty-five millimeters by forty-seven point five millimeters by one hundred forty-one point five millimeters and a weight of zero point two kilograms. Major applications of this module include infrastructure and energy management, material handling, and simple machine control. The product meets certification standards, including CE, CSA, and UL, and is suitable for wall mounting.
Discrete input base for distributed control
Features thirty-two channel status LEDs
Certified by CE, CSA, and UL
Product HighlightsPart of the flexible Modicon Momentum system, allowing for versatile control applications and easy snap-together installation.Product InformationStandard Information
Brand: Schneider Electric
Manufacturer: Square-D / Schneider
Technical Specifications
MPN: 170ADI35000
Depth: 47.5 mm
Width: 125 mm
Height: 141.5 mm
Weight: 0.2 kg
Current: 250 mA
Power Supply: 24 VDC
Response Time: 2.2 ms (state 0 to state 1), 3.3 ms (state 1 to state 0)
Vendor: SCHNEIDER ELECTRIC
Vendor Raw: SCHNEIDER ELECTRIC
Product Type: CONTROL BOARDS
Category: Electrical Supplies
Subcategory: Control & Circuit Boards
Subchildcategory: Control Boards
Availability Text: Out Of Stock
Brand: Schneider Electric
Manufacturer: Square-D / Schneider
MPN: 170ADI35000
Depth: 47.5 mm
Width: 125 mm
Height: 141.5 mm
Weight: 0.2 kg
Current: 250 mA
Power Supply: 24 VDC
Response Time: 2.2 ms (state 0 to state 1), 3.3 ms (state 1 to state 0)
