Product Description
The Rockwell Automation PowerFlex 755 AC Drive, model number 20G1AND125JA0NNNNN, is designed for various industrial applications. It features embedded Ethernet/IP for easy integration and communication. This drive provides standard protection, forced air cooling, and operates on an AC input with precharge. It is rated for one hundred twenty-five amps and supports up to one hundred horsepower in normal duty, and seventy-five horsepower in heavy duty, making it suitable for demanding environments.
Embedded Ethernet/IP for easy connectivity
Standard protection and forced air cooling
Rated for 125 amps and 100 HP ND
Product Highlights
Ideal for a range of applications, the PowerFlex 755 AC Drive provides reliable performance and flexible control options.
Product Information
Standard Information
Brand: Rockwell Automation
Part Number: 20G1AND125JA0NNNNN AB
Technical Specifications
Power Rating: 100 HP ND, 75 HP HD
Current Rating: 125 Amps
Voltage Rating: 480 VAC
Phase: 3 PH
Frame Size: Frame 6
Cooling Type: Forced Air
Installation Type: Open Type
Filter Type: Filtered
Product DescriptionThe Rockwell Automation PowerFlex 755 AC Drive, model number 20G1AND125JA0NNNNN, is designed for various industrial applications. It features embedded Ethernet/IP for easy integration and communication. This drive provides standard protection, forced air cooling, and operates on an AC input with precharge. It is rated for one hundred twenty-five amps and supports up to one hundred horsepower in normal duty, and seventy-five horsepower in heavy duty, making it suitable for demanding environments.
Embedded Ethernet/IP for easy connectivity
Standard protection and forced air cooling
Rated for 125 amps and 100 HP ND
Product HighlightsIdeal for a range of applications, the PowerFlex 755 AC Drive provides reliable performance and flexible control options.Product InformationStandard Information
Brand: Rockwell Automation
Part Number: 20G1AND125JA0NNNNN AB
Technical Specifications
Power Rating: 100 HP ND, 75 HP HD
Current Rating: 125 Amps
Voltage Rating: 480 VAC
Phase: 3 PH
Frame Size: Frame 6
Cooling Type: Forced Air
Installation Type: Open Type
Filter Type: Filtered
Vendor: ROCKWELL AUTOMATION
Vendor Raw: ROCKWELL AUTOMATION
Product Type: CONTROL BOARDS
Category: Electrical Supplies
Subcategory: Control & Circuit Boards
Subchildcategory: Control Boards
Availability Text: Out Of Stock
Brand: Rockwell Automation
Part Number: 20G1AND125JA0NNNNN AB
Power Rating: 100 HP ND, 75 HP HD
Current Rating: 125 Amps
Voltage Rating: 480 VAC
Phase: 3 PH
Frame Size: Frame 6
Cooling Type: Forced Air
Installation Type: Open Type
Filter Type: Filtered
Tags: loc_2, LTL
Source file: 20G1AND125JA0NNNNN - rockwell-automation-20g1and125ja0nnnnn-powerflex-755-ac-drive.json.json
| Brand | Rockwell Automation |
|---|---|
| Part Number | 20G1AND125JA0NNNNN AB |
| Power Rating | 100 HP ND, 75 HP HD |
| Current Rating | 125 Amps |
| Voltage Rating | 480 VAC |
| Phase | 3 PH |
| Frame Size | Frame 6 |
| Cooling Type | Forced Air |
| Installation Type | Open Type |
| Filter Type | Filtered |
| Vendor | ROCKWELL AUTOMATION |
| Vendor Raw | ROCKWELL AUTOMATION |
| SKU | 20G1AND125JA0NNNNN |
| Tipo de producto | CONTROL BOARDS |
| Disponibilidad | Out Of Stock |
| Nota LTL | LTL Delivery This product weighs 150 lbs each and will be shipped via LTL carrier. A lift gate option will be added free of charge for your convenience. |
| Moneda | USD |
| Handle Shopify | rockwell-automation-20g1and125ja0nnnnn-powerflex-755-ac-drive |
| Shopify Product ID | 9844744618290 |
| Peso | 150 lb |
| Peso gramos | 68039 |
| Código de barras | 889509000000 |
| Tags | loc_2, LTL |
| Razones sin stock | DOM: Availability indica “Out Of Stock” | DOM: Bloque NotifyMe visible | DOM: price--sold-out | DOM: ATC deshabilitado con “Sold out” | JSON: Ninguna variante disponible | JSON: product.available = false |
