Product Description
The Edwards 340-6G5 is a six-inch round vibrating bell designed to operate at twenty-four volts alternating current. It features a durable housing made from corrosion-resistant materials and is suitable for various applications including offices and factories.
Voltage Rating: 24 VAC
Current Rating: 0.35 Ampere
Sound Level: 102 dB at one meter
Product Highlights
This bell is UL approved, ensuring reliability across various environments.
Product Information
Standard Information
Mounting: Octagon Box/Singular Gang Box/Square Box/Surface
Approval: UL, CSFM, FM
Technical Specifications
Model Number: 340-6G5
Power Rating: 8.4 VA
Sound Intensity: 102 dB at 1 M, 92 dB at 10 Ft
Gong Size: 6 inch diameter
Physical Size: 7-1/8 inch diameter x 3-11/16 inches deep
Coil Resistance: 30 Ohm
Application: Office, Factory, Heavy Machine Shop
Housing Material: Corrosion Resistant Heat Flowed Epoxy Finished Die-Cast
Product DescriptionThe Edwards 340-6G5 is a six-inch round vibrating bell designed to operate at twenty-four volts alternating current. It features a durable housing made from corrosion-resistant materials and is suitable for various applications including offices and factories.
Voltage Rating: 24 VAC
Current Rating: 0.35 Ampere
Sound Level: 102 dB at one meter
Product HighlightsThis bell is UL approved, ensuring reliability across various environments.Product InformationStandard Information
Mounting: Octagon Box/Singular Gang Box/Square Box/Surface
Approval: UL, CSFM, FM
Technical Specifications
Model Number: 340-6G5
Power Rating: 8.4 VA
Sound Intensity: 102 dB at 1 M, 92 dB at 10 Ft
Gong Size: 6 inch diameter
Physical Size: 7-1/8 inch diameter x 3-11/16 inches deep
Coil Resistance: 30 Ohm
Application: Office, Factory, Heavy Machine Shop
Housing Material: Corrosion Resistant Heat Flowed Epoxy Finished Die-Cast
Vendor: EDWARDS
Vendor Raw: EDWARDS
Product Type: CONTROL BOARDS
Category: Electrical Supplies
Subcategory: Control & Circuit Boards
Subchildcategory: Control Boards
Availability Text: In Stock
Mounting: Octagon Box/Singular Gang Box/Square Box/Surface
Approval: UL, CSFM, FM
Model Number: 340-6G5
Power Rating: 8.4 VA
Sound Intensity: 102 dB at 1 M, 92 dB at 10 Ft
Gong Size: 6 inch diameter
Physical Size: 7-1/8 inch diameter x 3-11/16 inches deep
Coil Resistance: 30 Ohm
Application: Office, Factory, Heavy Machine Shop
Housing Material: Corrosion Resistant Heat Flowed Epoxy Finished Die-Cast
