Terminal de horquilla de bloque no aislado para cable de calibre 12-10 AWG, con perno de #6, paquete con 500 unidades.
| Wire Range | 12 to 10 AWG |
|---|---|
| Insulation Type | Bare |
| Stud Size | #6 |
| Insulation Color | Bare |
| Max. Voltage | 600 V |
| Seam | Butted |
| Standards | CSA Certified, UL Listed |
| Overall Length | 0.73 in |
| Terminal Connection | Crimp |
| Terminal Type | Block |
| Connection Type | Crimp |
| Max. Temp. | 347 deg F |
| Tongue Width - Wire Connector | 0.32 in |
| Item | Fork Terminal |
| Connection Material | Copper |
| Minimum Conductor Size | 12 AWG |
| Maximum Conductor Size | 10 AWG |
| Insulation Material | Non-insulated |
| Minimum Stud Diameter | 0.138 in |
| Package Quantity | 500 |
