Paquete de 1000 terminales de anillo de vinilo de calibre 16-14 para perno No. 8. Ideal para conexiones eléctricas seguras y confiables.
| Wire Range | 16 to 14 AWG |
|---|---|
| Insulation Type | Vinyl |
| Stud Size | #8 |
| Insulation Color | Blue |
| Connection Material | Copper |
| Terminal Connection | Crimp |
| Item | Ring Terminal |
| Standards | CSA Certified, UL Listed |
| Tongue Width - Wire Connector | 0.31 in |
| Max. Temp. | 221 deg F |
| Connection Type | Crimp |
| Overall Length | 0.93 in |
| Max. Voltage | 600 V |
| Seam | Brazed |
| Terminal Type | Standard |
| Maximum Voltage | 600 V |
| Maximum Conductor Size | 14 AWG |
| Connection Width | 0.164 in |
| Minimum Conductor Size | 16 AWG |
| Seam Style | Brazed |
| Tongue Width | 0.31 in |
| Maximum Wire Size | 14 AWG |
| Termination Style | Crimp |
| Minimum Wire Size | 16 AWG |
| Contact Material | Copper |
| Package Quantity | 1000 |
