Concrete Anchor, Permanent, 310 lb. Cap
| Item | Parapet Wall Anchor |
|---|---|
| Standards | OSHA, ANSI |
| Length | 22 in |
| Weight Capacity | 310 lb |
| Tensile Strength | 5,000 lb |
| Anchor Material | Steel |
| Attachment Point | D-Ring |
| Workers per System | 1 |
| Width | 15 in |
| Material | Steel |
| Installation | Temporary |
| Attaches To | D-ring Anchorage Plate |
| Color | Silver |
| Anchor Installation | Reusable |
| Overall Length | 22 in |
| Adjustment Style | Threaded Knob |
| Brand and Series | 3M DBI-SALA |
| Ring Inside Dia. | 3-3/4 in |
| Ring Diameter | 3-3/4 in |
| Number of Bolts Included | 3 |
| Detent Anchor Components | Not Applicable |
| Ring Inside Diameter | 3-3/4 in |
| Maximum Hole Depth | Not Applicable |
| ANSI Standards Met | ANSI Z359.18 |
| OSHA Standards Met | OSHA 1910.140, OSHA 1926.502 |
| Country of Origin (subject to change) | United States |
| Package Quantity | 1 |
