Epoxy Adhesive, Gray, 5/8 in Dia, 2 in L, 45 sec Begins to Harden, 528 PK
| Item | Epoxy Adhesive |
|---|---|
| Product Form | Smooth Sticks |
| Diameter | 5/8 in |
| Length | 2 in |
| Materials Bonded | Fabric, Foam, Metal, Plastic, Vinyl, Wood |
| Working Time | 45 sec |
| Melting Temperature | 350 Degrees to 385 Degrees F |
| Begins to Harden | 45 sec |
| Color | Gray |
| Electrically Insulating | No |
| High Tack | No |
| Series | 3748 |
| Melting Temp. - Glues | 175 Degrees F |
| Diameter - Glue Sticks | 5/8 in |
| Length - Glue Sticks | 2 in |
| Tensile Strength | 375 psi |
| Shear Strength | 250 psi |
| Peel Strength | 18 psi |
| For Use With | Mfr. No. POLYGUN TC |
| Application | Attaching Components on PC Boards, Cable Strain Relief, Coil Terminating, Potting, Product Assembly, Rigidizing Components, Wire Fastening |
| Full Cure | 24 hr |
| Temp. Range | -20 to 250 deg F |
| Characteristics | Good Thermal Shock Resistance, Non Corrosive to Copper for Many Electrical Applications |
| Substrates | Polyolefin |
| Green Environmental Attribute | Does Not Contain Methylene Chloride |
| Open Time | 45 sec |
| Features | 100% Solids, Fuel and Oil Resistant, Heat Resistant, High Temperature Stability, Impact Resistant, Low Temperature Thermal Shock Properties, Provides Optimal Adhesion In Fluctuating Temperatures, Thermoplastic Resin |
| Minimum Viscosity | 5,000 cps |
| Pressure Sensitive | Yes |
| Product Format | Smooth Sticks |
| UV Resistant | No |
| Low Odor | No |
| Maximum Performance Temperature | 250 deg F |
| Primary Applications | Plastics |
| Full Cure Time | 24 hr |
| Compatible Applicator Size | TC |
| Maximum Viscosity | 5,000 cps |
| FDA Compliance | 21 CFR 175.105 |
| Minimum Performance Temperature | -20 deg F |
| Material | Wood, Metal, Foam, Fabric, Plastic, Vinyl |
| Container Type | Can |
| Full Cure Time - Adhesives | 24 hr |
| Begins to Harden - Adhesives | 45 sec |
| Country of Origin (subject to change) | United States |
| Package Quantity | 528 |
