Heat Shrink Tube, Thin Wall, 2:1 I.D. Shrink Ratio, 0.06 in I.D. Before Shrinking, Clear, 4 ft
| Item | Heat Shrink Tube |
|---|---|
| Shrink Ratio | 2:1 |
| Wall Type | Thin Wall |
| Shrink Tubing I.D. Before Shrinking | 0.063 in |
| Shrink Tubing I.D. After Shrinking | 0.03 in |
| Material | Modified Polyvinylidene Fluoride |
| Color | Clear |
| Length | 4 ft |
| Use with Wire Size | 28 to 26 AWG |
| Temp. Range | -67° to 347°F |
| Min. Shrink Temp. | 250°F |
| Features | Offers Shrink-Fit Protection and Strain Relief Of Wires, Solder Joints, Terminals and Connections, Suitable for Marking Electronics and Appliances, Transparent Insulation for Easy, See-Through Inspection and Identification |
| Flame Retardant | Yes |
| Shrink Tubing Wall Thickness After Shrinking | 0.01 in |
| Max. Voltage | 600 V |
| Standards | AMS-3632, CSA, OFT Certified, RoHS 2011/65/EU, SAE AS23053/8, UL Listed |
| Adhesive Lined | No |
| Tubing Wall Type | Thin Wall |
| Shrink Tubing Properties | Abrasion Resistant, Acid and Alkali Resistant, Fuel and Oil Resistant, High Heat Resistant, Solvent Resistant |
| Dielectric Strength | 600 V |
| Max. Temp. Rating | 347 deg F |
| Min. Temp. Rating | -67 deg F |
| Package Style | Individual Pieces |
| Wall Thickness After Shrinking | 0.01 in |
| I.D. After Shrinking | 0.03 in |
| I.D. Before Shrinking | 0.06 in |
| Package Quantity | 250 |
