Hot Melt Adhesive, 2216 Series, Off-White, Pail, 2:03 Mix Ratio, 12 hr Functional Cure
| Item | Hot Melt Adhesive |
|---|---|
| Type | Part A |
| Application | May be applied with spatula, trowel, or flow equipment. |
| Color | Off-White |
| For Use On | Glass, Masonry, Metal, Plastic, Rubber, Wood |
| Container Type | Pail |
| Functional Cure | 12 hr |
| Full Cure | 7 day |
| Mixing Ratio | 2:03 |
| Shear Strength | 3,200 psi |
| Temp. Range | -65 to 300 deg F |
| Working Time | 90 min |
| Series | 2216 |
| Temp. Range (F) | -65 to 300 |
| Epoxy Max. Temp | 300 Degrees F and Above |
| Size | 5 gal |
| Shear Strength (PSI) | 2,500 |
| Structural Adhesive Type | Epoxy Adhesive |
| Work Life | 90 min |
| Epoxy Color | Gray |
| Epoxy Container | Pail |
| Includes | Hardener Only |
| Green Environmental Attribute | Does Not Contain Methylene Chloride |
| Coverage | 320 sq ft/gal |
| Application Method | Flow Equipment, Spatula, Trowel |
| Resin Type | Epoxy |
| Full Cure Time | 7 days |
| Hardener Color | Gray |
| VOC Content Weight | 3.7 g/L |
| Tensile Strength | 3,200 psi |
| Standards | UL 94 HB |
| Interior/Exterior | Exterior, Interior |
| Primary Applications | Potting |
| Low Odor | No |
| Total Volume | 5 gal |
| Cure Method | Ambient |
| Water Resistance | Not Water-Resistant |
| Peel Strength | 25 lb/in |
| Maximum Viscosity | 80,000 cps |
| Included Components | Hardener Only |
| Non-Sagging | No |
| Compatible Applicator | 3M EPX |
| Maximum Performance Temperature | 180 deg F |
| Hardness at Full Cure | 50 to 65 Shore D |
| Maximum Application Temperature | 80 deg F |
| Cured Color | Gray |
| Features | Flexible, Good Retention, Shock Resistant, Vibration Resistant |
| VOC Content Weight Percentage | Less Than 0.5% |
| Materials Bonded | Ceramic, Glass, Metal, Plastic, Rubber, Wood |
| Minimum Performance Temperature | -65 deg F |
| Marine Grade | No |
| Minimum Viscosity | 40,000 cps |
| Compatible Primer | EC-3901 |
| Hardener Volume | 5 gal |
| Container Type - Adhesives | Pail |
| Country of Origin (subject to change) | United States |
| Package Quantity | 1 |
