Desconexión macho, sin aislamiento, paquete de 500.
| Item | Male Disconnect |
|---|---|
| Insulation | None |
| Insulation Color | Bare |
| Insulation Type | Non-Insulated |
| Connection Type | #6 Ring to Male Tongue Adapter |
| Tab Size | 0.032 in x 0.250 in |
| Overall Length | 0.8 in |
| Seam | Butted |
| Max. Temp. | 347 deg F |
| Max. Voltage | 600 V |
| Connection Material | Copper |
| Standards | CSA Certified, UL Listed |
| Barrel Inside Dia. | 0.08 in |
| Tab Thickness | 0.032 in |
| Minimum Operating Temperature | 347 deg F |
| Terminal Type | Tab |
| Seam Style | Butted |
| Maximum Operating Temperature | 347 deg F |
| RoHS Compliant | Yes |
| Barrel Inside Diameter | 0.08 in |
| Termination Style | Crimp |
| Tab Width | 1/4 in |
| Contact Material | Copper |
| Maximum Voltage | 600 V |
| Insulation Material | None |
| Insulation Coverage | None |
| Package Quantity | 500 |
