Conector de compresión de terminal de ojal de un agujero, calibre 1 AWG, paquete con 100 unidades.
| Cable Size | 1 AWG |
|---|---|
| Connector Type | Seamless Barrel |
| Width | 0.65 in |
| Material | Copper |
| Length | 1.71 in |
| Color Code | Green |
| Item | Compression Lug Ring Tongue |
| Standards | CSA Certified, UL Listed |
| Tongue Style | Ring |
| Peep Hole | No |
| Stud Size | 5/16 in |
| Plate Material | Tin |
| Barrel Length | Short |
| Die Code | 11 |
| Hole Center to End | 0.35 in |
| Hole Center to Center | Not Applicable |
| Length (Straight Wireway) | 1.72 in |
| Tongue Length | 1.12 in |
| For Wire Size | 1 AWG |
| Inspection Hole | No |
| Contact Finish | Tin |
| For Conductor Material | Copper |
| For Stranded Copper Wire Size - Maximum | 1 AWG |
| Barrel Size | Short |
| Termination Style | Crimp |
| Tongue Thickness | 0.1 in |
| Seam Style | Seamless |
| For Wire Type | Stranded |
| Tongue Width | 0.65 in |
| Barrel Style | Seamless |
| Overall Length | 1.71 in |
| Barrel Inside Diameter | 0.36 in |
| RoHS Compliant | Yes |
| Overall Width | 0.65 in |
| Strip Length | 5/8 in |
| For Stud Size | 5/16 in |
| Tongue Angle | Straight |
| Special Features | Non-Insulated Construction |
| Package Quantity | 100 |
