Desconexión hembra Scotchlok, azul, calibre 16-14 AWG, paquete con 100 unidades.
| Item | Female Disconnect |
|---|---|
| Insulation | Partial |
| Material | Copper |
| Insulation Color | Blue |
| Wire Range | 16 to 14 AWG |
| Connection Type | Crimp |
| Insulation Type | Vinyl |
| Overall Length | 0.78 in |
| Tab Size | 0.020 in x 0.187 in |
| Seam | Butted |
| Max. Temp. | 221 deg F |
| Max. Voltage | 600 V |
| Connection Material | Tin-Plated Copper |
| Barrel Inside Dia. | 0.085 in |
| Standards | CSA Certified File No. LR22190, RoHS Compliant, UL Listed E70512 |
| Terminal Type | Female Disconnect |
| Fastener Orientation | Female |
| Mates with Male Tab Width (W') | 0.187 in |
| Disconnect Type | Female Disconnect |
| Male Tab Width (W') | 0.187 in |
| Solution for | Wireless Network Infrastructure Accessories |
| Mates with Female Width | 0.187 in |
| Tab Width | 1/4 in |
| Terminal Style | Standard |
| Maximum Insulation Outer Diameter | 0.145 in |
| Minimum Conductor Size | 16 AWG |
| Barrel Inside Diameter | 0.085 in |
| Pad Width | 0.187 in |
| Maximum Conductor Size | 14 AWG |
| Connection Width | 0.187 in |
| Package Quantity | 100 |
