MARS 43344 Low Pressure Control 15# Cut Out, 35# Cut In

Product Description

The MARS 43344 Low Pressure Control is specifically designed for precise and dependable pressure management in HVAC applications. This model features a 15 psi cut-out and 35 psi cut-in, providing automatic reset functionality to ensure consistent system operation without manual adjustments.

Pressure Range: 15 - 35 psi

Cut Out: 15 psi

Cut In: 35 psi

Connection Type: 1/4 inch SAE female flare

Durable and tamper-proof design for long-term reliability in residential and commercial air conditioning systems.

CSA certified and UL listed for compliance with safety and performance standards.

Product Highlights

Hermetically sealed sensor enhances durability and prevents tampering.

Direct mounting with 1/4 inch SAE flare connection simplifies installation.

Built to withstand up to 100,000 operating cycles.

Electrical connection via 18-inch wire leads with 1/2-inch stripped ends.

Technical Specifications

Contact Form: SPST, Close On Rise

Differential: +/-5 psi

Maximum Pressure: 35 psi

Operating Cycles: 100,000
